Sistema de filtración de cabina de lavado de Sgreen®
Descripción
BENEFICIOS
- Atrapa productos de desecho peligrosos, lo que protege su fontanería y medio ambiente
- Dejar de que la mueca de mierda déjese por el desagüe significa que las impresoras no tienen que preocuparse por pagar por un fontanero para arreglar sus tuberías
- Ayuda a las impresoras a mantener una tienda ecológica
El sistema de filtración Sgreen® es un sistema de filtración de tinta diseñado para eliminar los sólidos de desechos dañinos del proceso de limpieza de la pantalla mientras protege sus plomería y el medio ambiente de los subproductos dañinos. Incluso cuando se usa tintas y productos químicos ecológicos, el proceso de limpieza y recuperación de la pantalla puede hacer que los sólidos nocivos se descarguen por el desagüe. La colocación del sistema de filtración SGREEN® en su stand de lavado filtrará estos productos de desecho de su agua y le permitirá ejecutar una tienda más verde con una conciencia más limpia.
El sistema de filtración Sgreen® atrapa el agua a medida que sale del fregadero, enviándolo a través de seis etapas de filtración para el agua limpia óptima. La primera etapa es un filtro desechable que atrapa todas las partículas grandes de inmediato; Luego el agua pasa por una serie de tres pantallas reutilizables: 86, 156 y 200 malla. El agua filtrada luego fluye hacia un tanque de retención de la bomba donde se activa una bomba de sumidero industrial de alta potencia, empujando el agua a través de las dos etapas finales: un filtro de 70 micras y 20 micras. Con este proceso de filtrado de seis etapas, puede estar seguro de que el agua se ha filtrado varias veces, la mayoría de los sólidos se han eliminado y cualquier partícula restante se ha reducido a 20 micras, lo que le brinda agua limpia y un verdadero proceso de limpieza de pantalla ecológico .
VERIFICAREl catálogo de productos Sgreen
CARACTERÍSTICAS
- Limpia los subproductos dañinos de las aguas residuales.
- El proceso de filtrado de agua de seis etapas captura residuos que van desde las piezas de emulsión más grandes hasta las partículas de tinta más pequeñas.
- Recomendado para tiendas que ejecutan un solo auto o trabajan con hasta 100 pantallas por día.
- El aumento del volumen o el uso requerirá una limpieza más frecuente del sistema.
- Excelente solución para el final de un loto/auto-receptor una vez que los sólidos se eliminan inicialmente.
- Recomendado para practicar siempre la gestión de tinta inteligente.
- Carcasa de acero inoxidable.
- Seis filtros, que van desde una pantalla de malla 86 hasta 20 micras.
- El embalse tiene aproximadamente 22 galones estadounidenses (mientras opera)
- Caudal de la bomba (sin restricción): 36 galones por minuto
- Se necesita tamaño de la tubería de drenaje: 1-1/2 "
Filtros de reemplazo
- 16 x 20 OD 86 Pantalla de malla
- 16 x 20 OD 156 Pantalla de malla
- 16 x 20 OD 200 Pantalla de malla
- Filtro de 70 micras
- Filtro de 20 micras
- Alfombra de filtro verde
Dimensiones ensambladas
32 "L x 21" W x 20 "H con ruedas
Hojas de datos de productos
Pago y seguridad
Su información de pago se procesa de forma segura. No almacenamos los detalles de la tarjeta de crédito ni tenemos acceso a la información de su tarjeta de crédito.
Frequently Bought Together
- Reviews
- Questions
Thank you for submitting a review!
Your input is very much appreciated. Share it with your friends so they can enjoy it too!
- unit
- filtration system
- stages
- disposal
- environment
- investments
- screens
- issue
- inks
- cleaning

It works well, clean out process is a pain in the neck
The filtration unit works as intended and does exactly what it's supposed to. However, when designing the unit it doesn't seem much thought went into the cleaning process. You have to clean the screens used in the unit, however, there isn't any convenient way to do it. If you plan to reclaim them in your washout, then there's nothing filtering the runoff from you cleaning them and they're not in the unit. Like I said it works exactly as it's supposed to and filters your runoff from your wash out booth, but it very inconvenient to clean. So it's either you figure out a process to clean the screens or you end up buying new screens each time.
Amazing product!
I've had this product for about 5-6 months now and I've been very pleased with it. We recently moved our shop to a building i own(mortage) and do not lease. Being a screen printer for 14 years now I've seen the havoc that a washout booth will do to your plumbing. I ordered this product with the sump pump and I've been very pleased with it. I clean roughly 20-30 screens a week and end up cleaning the system about every 3-5 weeks. simply take out the screens and use a transfer tape squeegee to get the gunk into a plastic bag. The first set of micro filters lasted me about 4-5 months. I've replaced them with the included second set of filters... I did rinse the micro filters at the same time that I clean the filter screens, to get a little extra life out of them.. This system is great, it does require a little maintenance when you really just want to be doing something else. But the amount of "gunk" this will keep out of your plumbing is amazing. Also it's good for town water supply. Save your self from having to pay a plumber our fees from your local water supply.
Go Green!
Never did it cross my mind that one of my first investments in purchasing screen printing equipment would be a filtration system. I’ve always felt uncomfortable wondering how our environment can be impacted by improper disposal of unfiltered inks and chemicals. Thanks to the 6 stages of filtration this unit has to offer, I feel better about doing my part in preserving our environment...and you should too!

Purchased
I have purchased 2 of these for my new shop. I can’t wait to use them in 2023

CLEANING/MAINTENANCE
I think this filtration system is great, but as many have said, there just isn't really a good way to clean out the filtration screens, and the times in which I have been particularly busy, and needed to clean many many screens, I find that this is an issue....the screens get blocked and clogged up fairly quick. With that said, I honestly don't know what the solution to cleaning would be....I mean the gunk has to go somewhere right? It would be convenient if the screens (and unit) were a more standard size, so that you could just use screens you already have, that may be on their way out.
