Riley Pro Complete Screen Printing Shop Package

by Ryonet
Save 17%
Original price $20,986.00
Current price $17,395.00
SKU PKPO-PRO1-1

The Riley PRO series of packages are geared towards those looking for a turnkey higher production shop with everything needed to produce larger quantities of shirts from start to finish. With this package, you have the ability to do just about anything for a customer. The focus of the package is based around the easy to work with heavy-duty Riley 350 printing press. With this press at the center of your shop, everything else falls into place to make products move smoothly and quickly. In addition to the pre-press, darkroom, washout, and printing equipment we also include screens, inks, and chemicals. With this turnkey shop set up to compliment your screen printing operation all that is left to do is sell, sell, sell. It's time to rock n' roll!

This Kit Includes:

Riley 350 6 color, 6 Station Printing Press
Features and Benefits:

  • Sturdy, heavy-duty, lightweight construction.
  • XYZ: Micro Registration
  • Tool-Free Adjustments
  • Honeycomb Pallets
  • Adjustable Height Mechanism
  • 2-Point Roller Gate
  • Lifetime Limited Warranty
  • Diameter: 103"
  • Base Size: 57"
  • Platen Height: 35.5" - 36.5"
  • Platen Size: 16"x 24"
  • Max Platen Size: 24" x 32"
  • Min Frame Size: 23" x 31"
  • Max Frame Size: 25" x 36"
  • Max Frame Size(every other): 42" x 48"

    RileyCure 8 ft. Conveyor Dryer
    Features and Specs:

    • Overall Length: 96"
    • Overall Width: 34"
    • Overall Height: 41"
    • Belt width: 24"
    • Belt height: 30.3"
    • Belt drive: 120V
    • Belt speed: 1-12 feet/min
    • Output Rating: 200+ shirts per hour
    • Adjustable gates for optimal heat retention
    • Chamber length: 48"
    • 2 heat elements of 3050 watts each
    • Element voltage of 208 or 240
    • Wattage 6500 at 240volt
    • Amps 27
    • Plug is a NEMA L6-30P
    • 3-year warranty

      18" x 18" Riley Hopkins Infrared Flash Dryer
      Features and Specs:

      • Even heat distribution
      • Energy efficient
      • 3 year limited warranty
      • Watts: 2243
      • Volts: 120
      • Amps: 18.5
      • Size: 18"x18"
      • Plug Type: NEMA 5-20P

        Baselayr V2331 LED Exposure Unit

        FEATURES:

        • LED 405nm bulb technology
        • Digital timer for accuracy
        • Sturdy powder coated steel construction
        • EC power cord with easy access to an on/off switch
        • Flexible and durable rubber vacuum blanket
        • Heavy-duty gas shocks
        • Adjustable vacuum lid clamps
        • Optically clear, strong tempered glass
        • Two, light-safe T8 LED amber inspection bulbs
        • Oil-free vacuum pump
        • Includes nylon rope to allow air movement between the blanket and frame
        • 3-year limited warranty (please refer to manual for more information)
        • Made in USA

        PRODUCT SPECS:

        • Unit dimensions: 44"(L) x 32"(W) x 10"(H)
        • Optical clear, tempered glass: 31" x 38"
        • Max frame size OD: 23" x 31"
        • 8 UV T8 LED 405nm tube bulbs designed for screen exposure
        • Two, light-safe T8 LED Amber inspection bulbs with dedicated on/off switch
        • UV wattage: 320 watts
        • Voltage: 115v
        • Standard 110v 3-prong plug
        • Timer: Digital (1/10 sec. increments)
        • Control Panel and timer
        • Time adjustment
        • Timer on/off
        • Vacuum blanket on/off
        • Shipping dimensions: 40"(W) x 50"(L) x 12"(H)

              Sgreen Washout Booth 33"
              Features and Specs:

              • Dimensions: 33" x 24" x 63"
              • Easy-to-add backlighting (included)
              • Stainless steel basin
              • Aluminum siding
              • Rubber-protected edges
              • Sturdy structure
              • Easy cleanup
              • Low maintenance
              • Minimal space requirement
              • Easy to assemble
              • Effortless disassembly for transport


              Includes:

              • Wilflex Epic Spot Color inks: Quarts of Red, Blue, Gold, Purple, Green, Turquoise, and Gray.
              • Wilflex Epic Fashion Print Base Quart

              Complete Product and Chemical Kit

              Screens

              • 8 - 110 mesh 23" x 31" aluminum screens
              • 8 - 156 mesh 23" x 31" aluminum screens
              • 8 - 230 mesh 23" x 31" aluminum screens
              • 8 - 200 mesh 23" x 31" aluminum screens
              • 6 - 305 mesh 23" x 31" aluminum screens

              Inks

              • 9 Gallons of FN Plastisol Inks
              • -2 Gallons of FN White
              • -2 Gallons of FN Black
              • -1 Gallon of FN Royal Blue
              • -1 Gallon of FN Bright Red
              • -1 Gallon of FN Golden Yellow
              • -1 Gallon of FN Lemon Yellow
              • -1 Gallon of FN Kelly Green
              • 4 Quarts of the FN Plastisol Inks
                -FN Orange
                -FN Violet
                -FN Light Royal Blue
                -FN Fuchsia (magenta)
              • 1 Quart of Green Galaxy Pitch Black Water Based Ink
              • 1 Quart of Green Galaxy Neptune Blue Water Based Ink
              • 1 Quart of the Curable Reducer

              Chemical Kit Included

              • Baselayr Long Lasting Emulsion Gallon
              • Sgreen Supreme Wash Gallon by Franmar
              • Sgreen Aqua Wash Gallon by Franmar
              • Sgreen Emulsion Stripper Gallon by Franmar
              • Sgreen Adhesive Quart
              • Sgreen Stuff Dehazer Degreaser Quart
              • Ryo Screen Blockout Quart
              • Aqua Block Quart
              • Ryo Green Hand Cleaner Quart
              • 3 Blue Cleaning Brushes
              • 1 Container of Ryo Wipes

              Supplies Included

              • Digital non-contact laser temp gun
              • 12 - Goop scoops for easy ink handling
              • 1 - roll of 18" x 100 yards premium pallet protect tape
              • 8 - 15" squeegees
              • 8 - 12" squeegees
              • 4 - 8" squeegees
              • 4 - 6" squeegees
              • 1 - 16" emulsion scoop coater
              • 1 - 18" emulsion scoop coater
              • 100 black test square / printing pellon 14" x 16"
              • 100 white test square / printing pellon 14" x 16"
              • 3 - 2" X 36 yds. Green screen tape
              • 3 - 2" x 55 yds. White screen tape
              • 2 light safe yellow bulb
              • 1- 300PK of Ultimate Clean Up Cards
              • SG3000 Expert Spot Gun and Ryonet Cured Ink Spot Remover Qt.
