Riley Hopkins 360 Complete Screen Printing Shop Kit

Ready to kickstart your screen printing career into high gear? Start your screen printing business today with the Riley Hopkins® 360 Complete Screen Printing Kit.

Getting a kit makes your life simple. You could pick and choose supplies and equipment, but that takes a lot of time. With a few clicks, you have everything you need to start a print shop.

The kit has everything you need — a press, flash dryer, exposure unit, washout booth, screens, squeegees, inks, chemicals, and more. Loaded with top-notch equipment and supplies from brands like Riley Hopkins®, Baselayr®, Sgreen®, and FN-INK™, you can count on producing high-quality prints right from the start.

Investing in a shop package is an easy, economical way to start up or upgrade a screen printing business. Make your mark with the Riley Hopkins® 360 Complete Screen Printing Kit.

• Riley Hopkins® 360 6-Color, 4-Station Printing Press
• RileyCure 248 Conveyor Dryer
• Riley Hopkins® 16”x16” Flash Dryer
• Baselayr ® V2331 LED Exposure Unit
• Sgreen ® Washout Booth 33"
• Canon Pixma ix6820 Film Output Printer Package
• Easiway Dip Tank w/Solution
• Laser Guiding System
• Ink Kit
• 2 - Gallons of White FN-INK™
• 2 - Gallons of Black FN-INK™
• 1 - Quart of Bright Red FN-INK™
• 1 - Quart of Royal Blue FN-INK™
• 1 - Quart of Kelly Green FN-INK™
• 1 - Quart of Lemon Yellow FN-INK™
• 1 - Quart of Pitch Black Green Galaxy Water-Based Ink
• 1 - Quart of Neptune Blue Green Galaxy Water-Based Ink

• Supply Kit
• 8 - Baselayr ® 20”x24” 110 White Mesh Aluminum Screens
• 8 - Baselayr ® 20”x24” 158 White Mesh Aluminum Screens
• 8 - Baselayr ® 20”x24” 196 Yellow Mesh Aluminum Screens
• 6 - Baselayr ® 20”x24” 230 Yellow Mesh Aluminum Screens
• 1 - 100 pack of Baselayr ® 13x19 Waterproof Film
• 4 - 15” squeegees with 70 durometer
• 4 - 12” squeegees with 70 durometer
• 2 - 6” squeegees with 70 durometer
• 2 - EZ Grip Squeegees with 14” 70 durometer blade
• 1 - Digital Laser Temperature Gun
• 1 - 16”x100yd roll of FN-INK™ Premium Platen Tape
• 2 - 16” Scoop Coaters
• 1 - 300 pack of cleanup cards
• 1 - 25-pack of white test pellons
• 1 - 25-pack of black test pellons
• 2 - Rolls of 2”x36 yd of green screen tape
• 6 - Goop scoops
• Chemical Kit
• 1 - Gallon of Baselayr ® Long Lasting Emulsion
• 1 - Gallon of Sgreen ® Supreme Wash
• 1 - Gallon of Sgreen ® Aquawash
• 1 - Gallon of Sgreen ® Emulsion Stripper
• 1 - Quart of Sgreen ® Stuff Degreaser/Dehazer
• 1 - Quart of Sgreen ® Water-Based Pallet Adhesive
• 1 - Expert Spot Gun and a quart of Cured Ink Remover
• 1 - 6 Pack of Scrub Pads + 3 Scrub Handles


• Sturdy, heavy-duty, lightweight construction
• XYZ Micro Registration
• Adjustable Height Mechanism
• 4-Point Roller Gate
• Made in USA 🇺🇸
• Diameter: 100"
• Base Size: 60"
• Platen Height: 35" - 36"
• Max Platen Size: 30" x 32"
• Max Frame Size (Back Clamp): 25" x 36"
• Max Frame Size (Side Clamp): 23" x 32"
• Color/ Stations: 6 color / 4 station
• Shipping Weight: 602 lbs

• On/off switches for the belt, temperature, and dryer
• Temperature control
• Belt speed control
• Vented exhaust
• Adjustable gates
• Belt tracking guide
• Two locking casters, two rolling casters
• Dry-erase panel to write down specific settings
• 10-foot power cord
• Length: 96”
• Width: 36”
• Belt Width: 24”
• Belt Drive Power: Single Point Power
• Number of Elements: 2
• Heater dimensions: 18”x24”
• Chamber Length: 48”
• Chamber Height: 5”
• Entry/Exit Length: 24”, 24”
• Capacity: 300 shirts per hour
• Wattage: 6500
• Voltage: 240
• Amps: 27
• Plug Type: Nema L6-30P
• Made in USA 🇺🇸

• LED 405nm bulb technology
• Digital timer for accuracy
• Sturdy powder-coated steel construction
• EC power cord with easy access to an on/off switch
• Flexible and durable rubber vacuum blanket
• Heavy-duty gas shocks
• Adjustable vacuum lid clamps
• Optically clear, strong tempered glass
• Two, light-safe T8 LED amber inspection bulbs
• Oil-free vacuum pump
• Includes nylon rope to allow air movement between the blanket and frame
• Unit dimensions: 44"(L) x 32"(W) x 10"(H)
• Optical clear, tempered glass: 31" x 38"
• Max frame size OD: 23" x 31"
• 8 UV T8 LED 405nm tube bulbs designed for screen exposure
• Two, light-safe T8 LED Amber inspection bulbs with dedicated on/off switch
• UV wattage: 320 watts
• Voltage: 115v
• Standard 110v 3-prong plug
• Timer: Digital (1/10 sec. increments)
• Control Panel and timer
• Time adjustment
• Timer on/off
• Vacuum blanket on/off
• Made in USA 🇺🇸

• Dimensions: 33”W x 24”D x 63”H
• Easy-to-add backlighting
• Stainless steel basin
• Aluminum siding
• Rubber-protected edges
• Sturdy structure
• Easy cleanup
• Low maintenance
• Minimal space requirement
• Easy to assemble
• Made in USA 🇺🇸
• Effortless disassembly for transport
• Drain size: 1-½" Female nominal pipe thread drain (AKA 1-½ NPT)
• Maximum frame size is 23x31 (this will allow 4-5 inches on either side)

• Rotating, adjustable stand
• Locking casters
• 360° rotation
• Powder-coated to prevent rust
• Sturdy, simple design
• 9-foot power cord
• Easy assembly
• 1-year warranty
• Made in USA 🇺🇸
• Watts: 1600
• Volts: 120v
• Amps: 13.2
• Heater Size: 16”x20”
• Element Size: 16”x16”
• Plug Type: NEMA 5-15P

• Prints up to 14.5 ISO ipm* in black, up to 10.4 ISO ipm* in color
• Built-in wireless LAN (802.11b/g/n)
• Up to 9600 x 2400 optimized dpi color resolution
• Apple® AirPrint
• Produces up to 13" x 19" documents and photos
• Prints photos without borders
• ChromeLife100+ system Utilizes enhanced FINE print technology to create long-lasting photos when using select Canon papers and inks (not included).
• Prints on plain, super-high gloss, glossy, semigloss, matte and chlorine-free paper 150-sheet automatic input feeder.
• USB interface
